INDUSTRIAL / RAIL

Museum of The American Railroad Phase I & II
Location: Frisco, Texas
Services:
    ▪ Site plan alternative layouts for a 12.5 acre site in Frisco, TX
    ▪ Preliminary, design & construction phase engineering services for Phase I & II
    ▪ Site improvements, grading, storm drainage, utilities, fencing and 3,800 feet of rail
      track including connection to BNSF Railroad

Musket Amarillo Bio-Diesel Transload Facility

Location: Amarillo, Texas
Services:

   ▪ Prime Consultant for multi-discipline design team including civil, structural & electrical

    ▪ Design and construction administration for rail transload facility modifications
    ▪ Modifications of existing rail site including utilities, parking lot repairs, bio-diesel

      tanks, 3D product piping layout, electrical systems, and related improvements


Musket Greens Port Ethanol Terminal Expansion

Location: Houston, Texas
Services:

    ▪ Prime Consultant for multi-discipline design team including survey, civil, electrical

      & mechanical

    ▪ Preliminary, Design and CA services

    ▪ Site grading & 8” concrete paving plans for new left-turn lane and driveway entrance

      to Federal Road, storm drainage improvements and traffic control plan

    ▪ Design site grading, paving, storm drainage, water & sanitary sewer services, fencing,

      truck loading area, containment basin and rail transload design

TCB Interchange Tracks 1, 5 & 6

Location: Midlothian, Texas
Services:

    ▪ Civil design, design surveys & construction administration for 12,500 feet rail

      Interchange tracks 1, 5 & 6

    ▪ Storm drainage and site grading. Project was performed in three phases

BNSF/Musket Unit Train Terminal

Location: Fort Worth, Texas
Services:

     ▪ Civil design for 37-acre ethanol terminal
     ▪ Railroad design, drainage studies, preliminary storm water management plan

        including on-site detention, site grading plan, final storm drainage, and water & sanitary

        sewer utilities
     ▪ Design of rail facilities included mainline connections, 12,700 feet of rail track with

       capacity for 100 car unit train

TCB North Rail Loop Tracks 1, 2, 3 & 6 & Truck Drive

Location: Midlothian, Texas
Services:

     ▪ Fast track construction administration, civil design & surveying services for truck drive

       and rail service for rail transload facility
     ▪ Drainage studies, preliminary stormwater management plan, site grading, final storm

       drainage, utilities and railroad design. 8400 feet of rail lead, transload and storage tracks

Carry Transit Rail Transload Facility Phase I & II
Location: Arlington, Texas
Services:
    ▪ Preliminary & final civil design and construction administration for 7.5 acre rail
      transload facility
    ▪ Drainage system design, utilities, truck drives, parking lot, railroad tracks &
      related improvements
    ▪ Rail transload facilities included 6150 feet of rail storage and transload tracks



TCB US Polyco Transload Facility
Location: Midlothian, Texas
Services:

   ▪ Preliminary, Design & CA Phase Services

    ▪ Produced construction documents for grading plan for Truck Transit Drives, Parking Lot,

      Rail Transit & Transfer Tracks 1& 2, and Rail Transload Storage Area & Truck

      Transfer Area

    ▪ Designed rail and turnout installation for approximately 2,224 linear feet of track


dsgn_1441_img_1.jpgDSCN0412.JPGMARR_PH_II_Groundbreaking_(19)_3825.JPGNAVY_BLUE_2721.pngblue_1113.png

Crude Oil Rail Terminal
Location: Barnhart, Texas
Services:
    ▪ Prime Consultant for multi-discipline design team including Surveys, MEP & Civil

    ▪ Preliminary design for 25,000 feet of rail and related transload operations, crude storage

      tanks and truck loading operations

    ▪ Design and construction administration services for transport truck parking lot


Twin Oaks Power Plant Rail Loop Track
Location: Bremond, Texas
Services:

    ▪ Produced construction documents for over 15,000 feet of new rail to serve the Twin Oaks

      Power Plant in Bremond, Texas

    ▪ The design allowed for a unit train of coal to pull clear of the Union Pacific mainline track,
       unload and remain clear of the mainline as it waits for departure from the power plant
       facility

Musket Fort Worth Ethanol Terminal Expansion

Location: Fort Worth, Texas
Services:

    ▪  Prime Consultant for multi-discipline design team

     ▪  Added 3rd Truck Loading Bay including piping, electrical, security camera, shower etc
     ▪  Added Track#4 extension including piping connections & hose connections
     ▪  Provided design and Plans for on-site gas supply line for conversion from propane at

        VCU

     ▪  Rail crossing at South & North ends of tracks for access by track mobile



IMG_2665.JPGIMG_2747.JPGDSCN0810.JPGPict_77_4120.jpgDSCN3164_8942.JPGDSCN0317.JPGRecommend1.JPG

TCB Lot S Roller Compacted Concrete (RCC)
Location: Midlothian, Texas
Services:

      ▪ Provided project administration service and design construction plans
▪ The project included Roller Compacted Concrete (RCC) of 10,600 SY pavement work
   on the US PolyCo parking lot and driveways.
▪  Project scope also consists of RCC paving for the East-West road north of US Polyco
   site and the northeastern area off of East-West Road.




Carry Transit Sugar Track Addition

Location: Arlington, Texas
Services:

    ▪ Scope included installing new track alignment for cane sugar unloading track and
      pit for conveyor & additional sucrose mixing tanks.
    ▪ Pavement work & installation of storm drainage system for sugar blend area.
